Custom Manufactured Inductors & Coils
Captor offers build to print manufacturing and custom manufacturing of manual and automated inductors and coils. We provide custom designing to meet specific form, fit and function requirements and provide design, engineering, layout, manufacturing and assembly as well as testing, verification, consulting and R&D. Manufacturing a range of common inductors such as toroid inductors, common mode chokes, bobbin-wound inductors, tube-wound inductors, C-core inductors and air-core inductors in materials such as moly-perm alloy powder, nickel iron, silicone steel, ferrites and many others.
Wire sizes range from 4/0 to 40AWG with configuration, mounting and termination variations. Current is typically 0 to 1000 amps. Voltage ranges from 0 to 1000 VDC and 0 to 750 VAC with frequencies of DC to 400 Hz and available molded case packaging. For more on our build to print manufactured and custom manufactured inductor and coil capabilities, please see the chart below or contact us directly.
Portfolios
Custom Manufactured Inductors & Coils Capabilities
General Capabilities
-
Custom
Extensive Stock Material
Build to Print
Process
-
Design
Engineering
Layout
Manufacturing
Assembly
Testing
Verification
Consulting
Prototyping
Research and Development
Equipment
-
Automated
Manual
Common Inductors
-
Toroid Inductors
Common Mode Chokes
Bobbin Wound Inductors
Tube Wound Inductors
C-Core Inductors
Air Core Inductors
Materials
-
Moly-Perm alloy Powder
Nickel Iron
Powdered Iron
Silicon Steel
Amorphous Nano-Crystalline Structures
Ferrites
Many Others
Wire Size
-
4/0 to 40 AWG
Variations
-
Configuration
Mounting
Terminations
Terminations
-
Lead Wire
Custom
Packaging
-
Molded Case
Custom
Inductance
-
Microhenry (µH) to Millihenry (mH)
Current
-
0 to 1000 Amps
Voltage
-
0 to 1000 VDC
0 to 750 VAC
Frequency
-
DC to 400 Hz
Inspection
-
100% Test
Visual
AQL
Testing
-
Altitude
Temperature Cycling
Shock
Vibration
Electrical
Mechanical
Environmental
Quality Control
-
Test Plan
Test Report
Secondary Operations (In-House)
-
Assembly
Machining
Forming
Bending
Welding
Quick Turn Prototypes
Production Volume
-
Prototype to Medium Volume
Typical Lead Times
-
1 week (Stock)
10 to 12 weeks (Custom)
1 to 3 weeks (Prototype)
Additional Information
Industry Focus
-
Electrical
Electronic
Military
Aerospace
Commercial
Industry Standards
-
AS9100 Rev C
ISO 9001:2008
IPC 610
J-STD-001
File Formats
-
SolidWorks
AutoCAD
PCAD (Circuit Boards)
