Custom Telephone & Signal Line Filters
Custom Inductors & Coils
Cable Assembly Manufacturing
Contract Electronic & Electromechanical Mfg. Assembly & Box Build
Cylindrical Style Filters
Shielded Facility Room Power Line Filters
Aware of Captor Corp.'s expertise in electromagnetic interference, a customer contacted us for fabrication & design of a custom EMI filter.
This MIL-STD-188-125-1 and MIL-STD-188-125-2 compliant Control Line Filter was designed for use on a ground based program for protection of critical systems from HEMP (high-altitude electromagnetic pulse) conditions.
This Feedthru Capacitor was designed for a customer with a high voltage and high current application that had to have insertion loss performance across a wide band of frequencies.
Designed to convert 115 VAC, 3-phase, 400 Hz input to 270 VDC, 6.5 A output, this device incorporated custom internal wire harnesses, AC power line filter, DC power lines, and lightning protection.
Due diligence enabled us to find a suitable vendor for casting the aluminum housing with consistent dimensional accuracy at high production rates.
We assembled this Electromechanical Assembly with the AC and DC power lines, 115 VAC to 270 VDC rectifier, and DC-DC converter, the assembly incorporated multiple circuit cards, capacitor bank for voltage storage, and EMI filters for the power lines.
